LANWDM

Description

Ignis Photonyx’ LAN WDM MUX/DEMUX are designed based on array waveguide grating (AWG) principles and fabricated with silica on silicon planar lightwave circuits (PLC) technology. They can be applied to MUX/DEMUX for LANWDM4 40G, 100G, 400G and beyond.

Since MUX/DEMUX are data rate transparent, with properly designed integration interface, Ignis Photonyx’ PLC MUX/DEMUX help produce the smallest form factor TOSA/ROSA devices for all data rate applications, 40G, 100G, 400G, etc.

Features

• Deep UV stepper Lithography Technology
• 8 inch Silicon Semiconductor Process
• High Delta Technology
• Spot Size Convertor (SSC) Technology
• State of Art Design and Process
• Low Insertion Loss
• Low Crosstalk
• Small Polarization Dependence Loss
• Customize SSC available

Applications

• WDM system for Local Area Network Market
• Optimized package for CFP transceiver modules
• Following 100Gbps IEEE802.3ba standard
• 5G
• Internet Data Center
